Back Lit Troffer

Crafted for seamless integration into modern spaces, this lighting solution features a sturdy aluminum build with a low-profile design. Ideal for spaces with limited plenum, it fits standard 2×2, 1×4, or 2×4 grid ceilings, offering CCT and wattage selectability. This ensures a customizable lighting experience in commercial settings like open offices, classrooms, retail, and healthcare facilities, providing a soft and comfortable illumination.
Specification Sheet
Resources

Resources

Install Guides

  • The aluminum housing serves as an effective heat sink, optimizing the product’s lifespan.
  • Low profile design
  • This product is rated for operation in ambient temperatures ranging from -4°F to 104°F.
  • CCT Selectable: 3500K, 4000K and 5000K
  • Wattage Selectable
  • Efficacy 110lm/W standard and 125lm/W special order.**
  • 1-10V dimming
  • DIP switch featured for effortless customization, allowing smooth adjustments between three CCT options and wattage settings.

CCT

  • Field Selectable CCT
  • 3500K
  • 4000K
  • 5000K

Dimming Protocol

  • 1-10 V

Dimming Range

  • 10%
  • 5%
  • 50%

Efficacy

  • 110 lm/w
  • 125 lm/w

Lamp Source

  • LED

Listings

  • UL

Materials

  • Aluminum

Mounting

  • Arc
  • Ceiling
  • Grid
  • Plenum
  • Recessed

Voltage

  • 110-277 V
  • 120-277 V
  • 347 V

Watts

  • 6 w
  • 25 w
  • 30 w
  • 35 w
  • 40 w
  • 50 w
