SBK Turtle Friendly Roadway

LED Roadway Light

The Luminoso SBK Turtle Friendly Roadway light combines modern styling with the latest LED technology. It is available for specific caveats such as Roadway applications, with a wide variety of wattage ranging from 30 to 300 watts and either a 2M, 3M, 4M or 5M optic. Roadway lights are for roadway use only. Louvers and/or beachside shields must be installed for any fixture within line of sight of the beach and fixtures must be installed at the lowest mounting height practicable to meet FDOT Standards. FWC must be contacted for proper siting and shielding prior to installation.
Specification Sheet

Resources

  • Efficacy: >87-88 Lm/W
  • Input Power: 30W – 300W
  • Delivered Light Output: 2,728 – 24,904 Lumens
  • CCT: AMBER
  • Input Voltage: 120-277vAC/ 347-480 vAC Amps
  • THD: < 20% (at 120V)
  • Power Factor: >0.95 (120V)
  • Frequency: 50/60Hz
  • Standard Warranty: 5 Years
  • Standard Lifetime: Designed to L70 minimum 100,000 hours
  • Mounting: Horizontal Tenon
  • IP Rating: IP65 Wet Rated
  • High pressure die cast housing; anti-static powder paint
  • Mechanical Impact Resistance: IK08
  • 10K Surge Protection Device
  • Dimmable: 1-10V Dimming Capabilities
  • Ambient Temperature: -40 °F – 122 °F

CCT

  • 3000K
  • 5000K

Color / Finish

  • Black
  • Bronze

Controls Options

  • Photocell

Dimming Protocol

  • 1-10 V
  • DALI

Lamp Source

  • LED
  • OLED
  • UV

Materials

  • Aluminum
  • Metal
  • Polycarbonate

Ratings & Compliance

  • IK08
  • IP67
  • ISO 9
  • Turtle Safe

Static LED Color

  • Amber
  • White

Voltage

  • 120-277 V
  • 347-480 V

Watts

  • 5 w
  • 30 w
  • 31 w
  • 60 w
  • 61 w
  • 87 w
  • 90 w
  • 110 w
  • 120 w
  • 141 w
  • 150 w
  • 172 w
  • 180 w
  • 202 w
  • 210 w
  • 228 w
  • 234 w
  • 240 w
  • 256 w
  • 270 w
  • 274 w
  • 283 w
  • 300 w
  • 310 w
