HBLP

Flat Panel

Our Dual Selectable Backlit Panels are commercial luminaires that utilizes advanced driver technology to provide an all in one luminaire, providing 3 wattages and 3 CCT options in each size panel. This provides superior lighting performance while minimizing inventory by reducing the amount of stocking SKUs. They achieve high uniformity, DLC PREMIUM energy efficiency and reduced glare in typical T-bar grid ceiling applications. Our state-of-the-art backlit LED technology utilizes PMMA lensing over the LEDs which will not discolor over time. The need for a
light guide is eliminated, thus increasing photometric performance while keeping costs competitive. Combined with the rigid back enclosure that prevents warping in application, this
luminaire is designed for worry-free longevity and reliability. Available with factory installed battery backup for 90 minutes emergency egress illumination.
Specification Sheet

Resources

CCT

  • Field Selectable CCT
  • 3500K
  • 4000K
  • 5000K

Dimming Protocol

  • 0-10 V

Dimming Range

  • 10%

Efficacy

  • 110 lm/w
  • 125 lm/w

Lamp Source

  • LED

Listings

  • ETL

Materials

  • Aluminum
  • PMMA
  • Steel

Mounting

  • Ceiling
  • Grid

Ratings & Compliance

  • DLC
  • FCC
  • IC
  • Low UGR
  • RoHS

Static LED Color

  • White

Voltage

  • 120-277 V
