HBH3

LED Round High Bay

Introducing the HBH3 Series—a revolutionary solution to replace metal halide and high-pressure sodium lamped fixtures. Engineered with high efficacy chips, these high bays achieve an impressive output of up to 141 lumens per watt, effectively reducing energy expenses and streamlining maintenance requirements.

The HBH3 is the perfect choice for a wide range of applications, including factories, warehouses, and gymnasiums. Whether surface mounted or suspended with a hook and cord, it effortlessly illuminates large spaces with optimal efficiency. Say goodbye to outdated lighting systems and embrace the advanced performance of the HBH3 Series.
Specification Sheet

Resources

  • Sealed die-casting profile for indoor and outdoor applications.
  • Voltage,120-277V.
  • 97&215W CCT Selectable (4000K/5000K).
  • Lumen output from 6,600-30,500lm with efficacy up to 165lm/W.
  • 0-10V dimming.
  • Replacing 250W MH and 400W MH.
  • Operating temperature is -40ºF to 122ºF
  • UL and DLC
  • Hook mount, and surface mount** available.
  • 97W and 215W (120-277V)

CCT

  • Field Selectable CCT
  • 4000K
  • 5000K

Color / Finish

  • Black

Controls Options

  • Motion Sensor

Dimming Protocol

  • 0-10 V

Efficacy

  • 165 lm/w

Lamp Source

  • LED

Listings

  • UL

Ratings & Compliance

  • DLC
  • IP65

Shape

  • Round

Static LED Color

  • White

Voltage

  • 120-277 V

Watts

  • 97 w
  • 215 w
  • 250 w
  • 400 w
